The materials used are harmless to the environment
|
Specifications |
||||||||||
|
Style |
Minimum Thickness (inches)A |
Nominal Weight in lbs./100 Sq. Ft.B |
Design Size (inches)C |
Opening Size (inches)C |
Strand Size (inches) |
Overall Thickness (inches) |
Open Area |
|||
|
SWD |
LWD |
SWO |
LWO |
Width |
Thickness |
|||||
|
¼"-#20 |
0.026 |
74 |
0.250 |
1.05 |
0.092 |
0.715 |
0.079 |
0.029 |
0.029 |
37% |
|
¼"-#18 |
0.034 |
100 |
0.250 |
1.05 |
0.090 |
0.715 |
0.080 |
0.038 |
0.038 |
36% |
|
½"-#20 |
0.026 |
37 |
0.500 |
1.26 |
0.342 |
1.000 |
0.079 |
0.029 |
0.029 |
68% |
|
½"-#18 |
0.034 |
61 |
0.500 |
1.26 |
0.306 |
1.000 |
0.097 |
0.038 |
0.038 |
61% |
|
½"-#16 |
0.043 |
77 |
0.500 |
1.26 |
0.304 |
1.000 |
0.098 |
0.048 |
0.048 |
61% |
|
½"-#13 |
0.066 |
126 |
0.500 |
1.26 |
0.286 |
1.000 |
0.107 |
0.072 |
0.072 |
57% |
|
¾"-#16 |
0.043 |
47 |
0.923 |
2.10 |
0.701 |
1.750 |
0.111 |
0.048 |
0.048 |
76% |
|
¾"-#14 |
0.054 |
56 |
0.923 |
2.10 |
0.713 |
1.760 |
0.105 |
0.060 |
0.060 |
77% |
|
¾"-#13 |
0.066 |
67 |
0.923 |
2.10 |
0.711 |
1.781 |
0.106 |
0.072 |
0.072 |
67% |
|
¾"-#10 |
0.066 |
102 |
0.923 |
2.10 |
0.603 |
1.755 |
0.160 |
0.072 |
0.072 |
65% |
|
¾"-#9 |
0.101 |
157 |
0.923 |
2.10 |
0.593 |
1.688 |
0.165 |
0.108 |
0.108 |
64% |
|
1"-#16 |
0.043 |
38 |
1.000 |
2.52 |
0.804 |
2.250 |
0.098 |
0.048 |
0.048 |
80% |
|
1½"-#16 |
0.043 |
35 |
1.330 |
3.15 |
1.092 |
2.750 |
0.119 |
0.048 |
0.048 |
82% |
|
1½"-#14 |
0.054 |
43 |
1.330 |
3.15 |
1.098 |
2.750 |
0.116 |
0.060 |
0.060 |
83% |
|
1½"-#13 |
0.066 |
51 |
1.330 |
3.15 |
1.098 |
2.750 |
0.116 |
0.072 |
0.072 |
83% |
|
1½"-#9 |
0.101 |
105 |
1.330 |
3.15 |
1.014 |
2.563 |
0.158 |
0.108 |
0.108 |
76% |
