Fuel cell is a power generation device that directly converts chemical energy existing in fuel and oxidant into electrical energy. Fuel and air are sent into fuel cells respectively, and electricity is produced wonderfully. It looks like a battery with positive and negative electrodes and electrolytes, but in essence it is not a "storage" but a "power plant".


Titanium and Nickel micro expanded metal is a type of metal that has been expanded with a variety of small holes, in order to create a lightweight material with a higher surface area-to-weight ratio than standard sheet metal. It is often used in applications where strength, stability, and accuracy are important, such as in the manufacture of industrial filters and mesh electrode. Designed for use in scientific applications and challenging technology, micro expanded mesh is an extremely precise product that retains all of the benefits of expanded metal mesh.



Advantage:

-Outstanding mechanical strength (Anti-ravel and Flexible)
-Micro expanded metal is a cost-effective alternative to perforated metal – especially when using -high-value raw materials
-Can be manufactured according to the end user’s exact requirements
-Precision expanded metal mesh product for specialist industry needs
-Can be used in many fields including engineering and manufacturing









SILVER MICRO EXPANDED MESH（SILVER-ZINC CELL）



MATERIAL

SILVER

STRAND

0.06–1.2 mm

LWD*SWD

0.5 × 1.0 mm, 1.0 × 2.0 mm, 1.25 × 2.5 mm, 1.5 × 2.5 mm, 1.5 × 3.0 mm，3.0 mm × 6.0 mm，4.0 mm × 8.0 mm，5.0 mm × 10.0 mm，10.4 mm × 16.0 mm

WIDTH

15–600 mm ± 0.4 mm

THICKNESS

0.05–1.5mm ± 0.01 mm

DESITY

100–2905 g/m2 ± 20 g/m2

TOUGHNESS

NO BROKEN WHEN CRUVE 15TIMES AT 180 DEGREE

LENGTH

ABOVE 300M NO EXCEED 2 JOINTS

TENSILE STRENGTH

≥ 3 kg(Sample width:50 mm，Length:350 mm) 3000N/MM2

ENLONGATION

≤ 3%(Sample width:50 mm，Length:350 mm) BELOW 3%
